Inhibit rig trolley design.
Design includes a secure location for a 600mm diameter, 45 gallon oil drum and an oil storage tank.
Trolley allows for engine parts to have oil hand pumped from the barrel through them and then drained into the dirty oil tank. The dirty oil tank feature a drain tap for draining.
Manufacture main frame from mild steel and oil storage tank from stainless steel. Approx size: 760mm (width) x 1470mm (length) x 1066mm (high).
Assembled with hand pump and 125mm diameter castors, two fixed, two swivel with brake. Each castor has a SWL of 200kg.
Unladen weight 285kg. Approx total weight inc oil drum and full oil storage tank 690kg.
