Fixed Back Creeper Trolley

Fixed Back Creeper Trolley The Fixed Back Creeper Trolley has been designed for a client that repairs and maintains equipment to ensure services are conducted in an optimal sitting position. The framework, formed from two types of thin square box…

Read More

Monitor Pole

Monitor Pole – REF 2017-02-13342 The Monitor Pole has been designed to securely store a 10″ Samsung LED monitor to provide a POS solution within a major electronics manufacturers store. The solution will be installed in stores across the country.…

Read More

AETC Transport Trolleys

We recently completed an order for 10 AETC Transport Trolleys – REF 2015-05-11725 Project Scope: Produce CAD design and manufacture AETC Transport Trolleys. Design Scope: The AETC transport trolleys have been designed to safely transport wax moulds of varying shapes and sizes. The…

Read More

2013-10-10332 – Lamp Brackets

Lamp Brackets Design. The lamp brackets have been manufactured to the customers requirements using their drawings for the SBR/PSR bracket. They have been laser cut and then CNC formed from 1mm Aluminium. The brackets have a self colour finish as…

Read More

AD-198-2013-07 – ITT Portable Cabinets

ITT Portable Cabinets Design. The cabinets will be used to transport and securely store the ITT equipment, the framework is manufactured from 40mm x 3mm SHS and 1.2mm sheet metal infill panels. A full length lockable roller shutter door allowing full…

Read More

2010-03-7370 – Inhibit Rig Trolley

Inhibit rig trolley design. Design includes a secure location for a 600mm diameter, 45 gallon oil drum and an oil storage tank. Trolley allows for engine parts to have oil hand pumped from the barrel through them and then drained…

Read More

AD-178-2013-06 – Foam Tray Cut with Tool Profiles

Manufacture profiled foam inlay for tool storage container. The foam inlay will securely hold the grinding wheel, locating spindle, polishing stick and spanner. The main body of the tray will be black and the backing will be red. When the tooling is missing this…

Read More

2013-07-10168 – Cable Clamp

Manufacture Cable Clamp to drawing number 3EER 200011-939. Manufacture from Nylon 66 (Black). All sharp edges to be deburred. Approx. size: 96mm x 52mm x 30mm. 1 cable entry hole 35mm, 1 cable entry hole 30mm. 52mm centres. 9mm through…

Read More

AD-62-2013-02 – Fan Trolley

The trolleys will be designed to carry the Blade Wash Baskets, the baskets will be lowered on the trolley via a gantry crane, a 110volt 600mm diameter fan will then pivot into position over the basket allowing cold air to…

Read More

2012-10-9589 – Transportable Magnetic Notice Wipe Board

Manufacture magnetic notice boards. The boards will be fabricated from 50mm x 30mm box section and fitted with pressed reinforced 1.2mm sheet. They will be powder coted to give a hardwearing durable finish and assembled with 125mm diameter castors. The…

Read More
