Assembly Solutions

Quality, innovative products by using technology, experience and a belief in continual improvement.

C Class Trolley

C Class Trolley The C Class Trolley has been redesigned and manufactured for a Midlands based Aerospace OEM to hold euro boxes in conjunction with existing media. The framework has been manufactured from 25 x 25 steel box section and 40…

Read More

Working Height Trolley

Working Height Trolley The Working Height Trolley has been designed and manufactured for a Midlands based Aerospace OEM to safely transport euro boxes to the inspection area. The frame has been fabricated from thin 25 x 25 steel box section and…

Read More

Lathe Fixture Racking Trolley

Lathe Fixture Racking Trolley The Lathe Fixture Racking Trolley has been designed and manufactured for a subsidiary of a leading aerospace company to allow easy transport and storage of billets or tooling. This is a universal trolley which an be adapted for numerous…

Read More

Large 6 Drawer Toolchest

Large 6 Drawer Toolchest The Large 6 Drawer Toolchest has been developed for a leading gas turbine engine provider. The tool kit has been designed to accompany gas turbine engines and provide all the tooling required to maintain the engine. This is a larger variation…

Read More

GG Build Stand

GG Build Stand: The build stand was designed to hold and assist in the assembly of three different size rotors, featuring interchangeable centre plate locating sections to accommodate each rotor size. Universal stabilising arms with PTFE clamping blocks attached fit…

Read More

Lifting Bar XPE 1304

Lifting Bar XPE 1304 Design The Lifting Bar is designed to handle XWB, T700, T900 engine parts for the wash process giving more versatility to the operators. The main support bar is manufactured from 30mm 304 stainless steel round with…

Read More

2010-03-7370 – Inhibit Rig Trolley

Inhibit rig trolley design. Design includes a secure location for a 600mm diameter, 45 gallon oil drum and an oil storage tank. Trolley allows for engine parts to have oil hand pumped from the barrel through them and then drained…

Read More

AD-145-2013-04 – J & S Cell Tray Rack and Workstation

Manufacture J & S Cell Tray rack and Workstation to drawing number AD-145-2013-04-1. The framework will be assembled from 40mm x 40mm heavy duty extruded aluminium profile and fitted with 100mm diameter swivel and braked castors. The interior framework of…

Read More

2012-04-9178 – Preload Station

The table framework will be assembled from 40mm x 40mm heavy duty extruded aluminium profile The upper section interior framework of the station will consist of angle runners for blade trays and a drawer to hold 1 off blade tray.…

Read More

AD-143-2013-03 – Rotating Bed

Produce CAD drawings and manufacture Rotating Bed to drawing number AD-143-2013-03-1. The fixed base frame will be fabricated from 160mm x 80mm rectangular hollow section and feature a tubular centre pivot point. Adjustable nylon guides that locate around the pivot…

Read More
